Hangzhou kgooer electronic technology co., LTD

LJTH-3.2/100

Feature Description:
with dual-core CPU, with 5-inch TFT touch screen;
support external SD card storage;
with overvoltage, overcurrent, overheating and other protection functions;
activation function: in the battery is offline, you can activate a single battery;
Discharge function: Constant flow check discharge with intelligent dummy load when battery is offline;
Charging function: the battery can be automatically charged when the battery is in the online float or offline state;
internal resistance fast test function: (optional) in the battery pack from the system after the discharge, just 1 to 2 minutes to measure the battery capacity,
equipped with host computer operating software, software, data management powerful, user-friendly, providing data management, printing, analysis, reporting systemMeter, automatically generate test reports and other functions.

Technical parameters	rating	Notes
Single voltage measurement type	3.2V	...
Unit voltage measurement range	3.2 (2 ~ 5V)	...
Voltage test accuracy	0.5%	...
Charge and discharge current operating range	1A ~ 100A	...
charge and discharge current control accuracy	0.1A	...
current test accuracy	1%	...
Operating voltage	AC 220 ± 15%	...
Cooling method	forced air cooling	...
storage conditions	USB	...
display mode	-20 ℃ ~ 70 ℃ packaging storage	...
weight	11kg	...
