| Technical parameters | The rated specification | note |
| Module supply voltage | DC24V±20% | ... |
| Maximum power supply | 7W | ... |
| Battery monitoring section | 48 | Single maximum support. |
| Voltage detection range | 1.0～18.0V | ... |
| Voltage precision | ±0.1% | ... |
| Temperature testing quantity | 48 | Single maximum support. |
| Temperature detection range | -40～105℃ | ... |
| Temperature detection accuracy | ±1℃ | ... |
| Input insulation resistance | ≥10MΩ,1000VDC | ... |
| Data communication interface | CAN*1 | ... |
| Communication baud rate | 250Kbps | ... |
| Dry contact output | 2A@250VAC/30VDC | 3 |
| Size and weight | 260×126×45(mm)/1.5Kg | ... |
| installation | Wall hanging | ... |
